25 Series Intelligent Pressure and Level Transmitters

Collection image

Series Overview

  • Ranges from -160 inH2O vacuum to 1,160 psig
  • HART® protocol output available
  • 316 Stainless Steel wetted parts
  • Strong flush diaphragm with minimal fill volume
  • Can be cleaned-in-place (CIP) or steamed-in-place (SIP)
  • Meets the requirements for 3-A

Documents

▼
PDF Data Sheet PDF User Manual Image Wiring Diagram
Part NumberTri-Clamp SizePressure Range
254-16-40/160inH2O-1-43-71-TC 2 in 0 to 160 inH2O|0 to 40 inH2O|1.45 to 5.8 psig
254-16-29/145-1-43-71-TC 2 in 0 to 803 inH2O|0 to 4017 inH2O|29 to 145 psig
254-16-16/40inH2O-1-43-71-TC 2 in 0 to 16 inH2O|0 to 40 inH2O
