About
- Gauge, compound, absolute and vacuum ranges from 2 psig to 15,000 psig
- Premium accuracy
- Current and voltage outputs available
- 316 and 17-4PH Stainless Steel wetted parts
- CE compliant to suppress RFI, EMI and ESD
Featured Specifications
Pressure Range
0 to 10000 psi gauge
Process Connection
1/4" NPT Male
Electrical Connection
DIN form C
Documents
Marketing Flyers
Product Specifications
▲| Pressure Range | 0 to 10000 psi gauge |
| Accuracy | ±0.25% of span, non-linearity best fit straight line per IEC 61298-2 at reference conditions |
| Output Signal | 4 mA to 20 mA, 2-wire |
| Process Connection | 1/4" NPT Male |
| Electrical Connection | DIN form C |
| Power Requirement | 10 Vdc to 30 Vdc |
| Environmental Rating | IP65 |
| Materials of Construction (Wetted Parts) | 316 Stainless Steel with 316 Stainless Steel housing |
| Media Temperature Range ºF | -20 to 212 ºF |
| Media Temperature Range ºC | -30 to 100 ºC |
| Media Temperature Range ºF | -20 to 212 ºF |
| Media Temperature Range ºC | -30 to 100 ºC |
| Applications |
|
Applications
▲| Application |
|
