High Performance Fixed Range Pressure Transmitter, 0 to 5000 psi gauge, ±0.25% of span, non-linearity best fit straight line per IEC 61298-2 at reference conditions, 0 Vdc to 10 Vdc, 3-wire, 7/16-20 male SAE - 4 (J1926-2), M12 x 1 4 pin
Featured Specifications
Pressure Range
0 to 5000 psi gauge
Process Connection
7/16-20 Male SAE-4 (J1926-2)
Electrical Connection
M12 x 1 4-pin
Dimensions
Additional Dimensions
Marketing Flyers Product Specifications
▲| Pressure Range | 0 to 5000 psi gauge |
| Accuracy | ±0.25% of span, non-linearity best fit straight line per IEC 61298-2 at reference conditions |
| Output Signal | 0 Vdc to 10 Vdc, 3-wire |
| Process Connection | 7/16-20 Male SAE-4 (J1926-2) |
| Electrical Connection | M12 x 1 4-pin |
| Power Requirement | 12 Vdc to 36 Vdc |
| Environmental Rating | IP67 |
| Materials of Construction (Wetted Parts) | 316 Stainless Steel with 304 Stainless Steel housing |
| Media Temperature Range ºC | -30 to 105 ºC |
| Media Temperature Range ºF | -22 to 221 ºF |
